Installing the CPU cooler on an Intel

LGA775 CPU

To install the CPU cooler onto an Intel LGA775 CPU:

1 Install the four large screws (C)

counterclockwise into the two LGA775

retention brackets (D).

2 Attach the retention brackets to the

bottom of the CPU cooler with the small

screws (E), with the large screws

pointing up, then insert the

anti-vibration pads (F) onto the screws.

08-1280_RF-UCPUCF - ENG.fm Page 8 Wednesday, June 11, 2008 3:43 PM
